Garmin ECHOMAP UHD 73cv with LakeVu G3 and Transducer

Garmin ECHOMAP UHD 73cv with LakeVu G3 and Transducer

Garmin’s ECHOMAP UHD 73cv offers a 7” sunlight readable, key assisted touchscreen display with detailed LakeVu G3 Mapping with Navionics data covering more than 17,000 US lakes with 1’ contours. Includes GT24 UHD Transducer for Ultra-High Definition clearvu scanning sonar below your boat!

  • SKUGA0233401
  • MAN#010-02334-01
  • ID#: 6183
(Rating 84)
Our Price:
$699.99
Availability:
In Stock
Shipping:
FREE 2 Day Air!
Condition:
Brand New
free premier shipping

7” GPS/Fishfinder with LakeVu G3 Maps and Ultra High Def Sonar images!

Marine GPS Has Echo Sounder Has Touch Screen Waterproof Sunlight Viewable

With the introduction of the ECHOMAP UHD Chartplotter/Fishfinder combinations, you can now see below your boat with exceptional target separation and near photo like detail with the included GT24 UltraHigh Definition Transom mount transducer!

Garmin offers several Premium chart options for this Garmin display including Garmin Navionics Vision+ charts. Garmin Navionics Vision+ charts include both coastal and inland coverage within the region of your choice. Data is sourced from Garmin and Navionics in order to provide you with exceptional detail. These charts include 1-year of daily updates, ensuring your chart data is always current! Premium features include High Resolution Relief Shading, High Resolution Satellite Imagery, Sonar Imagery, Aerial Photography, SideScan Images and More! Garmin Navionics Vision+ charts require premium content to be downloaded post purchase. Other chart options for this unit include Garmin BlueChart G3 Vision and Garmin LakeVu Ultra charts. All premium chart options are available in the region of your choice and sold separately.

Compatible with Garmin Navionics Vision+

Built with an internal Ultra High Definition scanning sonar and paired with a GT24 UHD transducer, the 73cv provides Ultra High Definition ClearVu reaching depths of 200’ and high frequency chirp reaching depths of 800’. ClearVu sonar offers a photo like image down to 200 feet below the boat where you can actually see rocks, brush piles, and even a ship wreck making it great for bottom fishing while the High Frequency Chirp sonar sends down multiple frequencies, providing great target separation in the water column. You can see the difference between small and larger fish and even see individual fish swimming in bait balls. Both transom and trolling motor mounts are included for quick installation and includes 20’ of transducer cable. An accurate temperature sensor is also included in the GT24UHD-TM. Fully compatible with the Force Trolling Motors, Panoptix Livescope and Panoptix PS line of forward and down scanning sonars, the Panoptix all seeing sonar is like no other sonar offered, especially to see below and in front of your boat in real time, up to 100ft. away.

Compatible with Panoptix

With multiple network options, the 73cv offers WiFi, NMEA2000, NMEA0183 and ethernet networking to connect to additional displays, tablets, AIS, VHF, Autopilots and more. The built in Wi-Fi connects wirelessly with the ActiveCaptain App that can be downloaded to your smart phone or tablet and allows you to update or purchase/download new charts quickly and easily. With Ethernet networking you can now enjoy sharing sonar and user data between two ECHOMAP UHD or ECHOMAP Ultra units (7x and 9x models only) via Ethernet cable. Full NMEA 2000 connectivity allows your ECHOMAP UHD to share information such as engine data, Fusion-Link audio information, autopilot connectivity, and more.

For a simplified sonar solution with high class features, the Garmin ECHO MAP UHD 73cv with GT24 UHD transducer is the unit of choice!

*All echomap UHD units include coverage of the Great Lakes. ECHOMAP UHD units with preloaded LakeVu Maps (63,73,93) include coverage of the Great Lakes, US Side Only. ECHOMAP UHD Units with preloaded Bluechart G3 (64,74,94) include coverage of both the US and Canadian side of the Great Lakes.

Garmin ECHOMAP UHD 73cv Box Contents
Each Garmin ECHOMAP UHD 73cv Comes with:
  • ECHOMAP UHD 73cv with LakeVu G3 for US Lakes
  • GT24UHD-TM transducer with Depth and Temp Readings and 20’ Cable
  • Power/data cable
  • Tilt/swivel mount with quick release cradle
  • Flush mount
  • Protective cover
  • Hardware
  • Documentation
  • Two Year Warranty
Garmin ECHOMAP UHD 73cv Key Features
  • Preloaded with LakeVu G3 Maps covering more than 17,000 lakes with 1’ contours
  • CHIRP ClearVu Sonar with Included GT24UHD Transducer
  • 7” Key Assisted Touchscreen display
  • NMEA2000 and NMEA0183 Support
  • Compatible with Force Trolling Motor and Panoptix
  • Size: 9.8"W x 5.5"H x 2.0“D

ECHOMAP UHD 73cv
# Of Waypoints # Of Routes Track log Receiver Type Display Size
5,000 100 50,000 points 50 saved tracks 5Hz GPS receiver Color 7" Diag. 400 x 800
Garmin ECHOMAP UHD Installation Instructions- Click Here
Garmin ECHOMAP UHD 7” Flush Mount Template- Click Here
