Garmin ECHOMAP UHD2 73sv Ice Fishing Bundle with Garmin Navionics+ Lake Charts

Free Ground Shipping!

Garmin ECHOMAP UHD2 73sv Ice Fishing Bundle with Garmin Navionics+ Lake Charts

Enjoy clear, high-contrast sonar views anywhere you fish! The ECHOMAP UHD2 73sv Ice Fishing Bundle features a 7-inch hybrid-touch display, preloaded Garmin Navionics lake charts and GT10 high/narrow CHIRP traditional ice fishing transducer. A built-in flasher provides precise jig and fish detection, while custom combination pages combine sonar, flasher and charts!
  • SKUGA0268435
  • MAN#010-02684-35
  • ID#: 7618
(Rating 90)
Our Price:
$749.95
Availability:
Usually Ships in 3-5 Days
Shipping:
Free Ground Shipping!
Condition:
Brand New


Garmin's ECHOMAP UHD2 73SV with GT10HN-IF Transducer enhances your ice-fishing experience! Packaged with a 7" touchscreen display with a built-in flasher and preloaded with detailed Lake Maps, the 73sv comes with a GT10 High Narrow Ice Fishing Transducer, Tilt-Swivel Mount, Portable Bag, Based/Handle, Foam Float, Power Cable, Rechargeable Battery and Battery Charger providing everything you need to a day out on the ice!

Detailed Charts! Preloaded with Garmin Navionics+ Mapping for the Inland Lakes, the integrated chart data covers over 23,000 lakes with 1' contours and can easily be enhanced with additional charting via the microSD card slot. Garmin offers several Premium chart options for this unit. Available by region, Garmin Navionics Vision+ charts include both coastal and inland coverage. Data is sourced from Garmin and Navionics in order to provide you with exceptional detail. These charts include 1-year of daily updates, ensuring your chart data is always current! Premium features include High Resolution Relief Shading, High Resolution Satellite Imagery, Sonar Imagery, Aerial Photography, SideScan Images and More! Garmin Navionics Vision+ charts require premium content to be downloaded post purchase.

Compatible with Garmin Navionics Vision+

The included GT10HN-IF transducer provides 500w high-narrow CHIRP sonar (130-300kHz) image for exceptional clarity, target separation, and detailed images below the ice. The narrow 7-16 degree beam angle and overall shape of this transducer has been optimized for ice fishing and offers precise fish and jig detection. Built to last, the GT10HN-IF is made with a silicone coated cable that remains flexible in harsh winter conditions.

Scanning Sonar and Livescope Compatible! Pair with a compatible ClearVu and SideVu transducer for nearly photographic images of whats below the boat! View advanced, Real time sonar images of structure, bait and fish swimming around your boat with Livescope Sonar. Pair your ECHOMAP UHD with a Livescope Sonar system and view underwater detail like never before! Built with AHRS (Attitude Heading Reference System), Livescope ensures your sonar view stays stable even in rough seas! LiveScope Down provides images of structure and swimming fish up to 200' below your boat while the Live Scope Forward will assist you in scouting and locating fish that are swimming ahead of your cast up to 200'. Easily adjustable, the Live Scope can be set to the mode that works best for your fishing needs. With exceptional views and sonar capabilities you can not only see what going on in real time, you may with just a bit of practice even be able to differentiate between fish species! *Livescope System Sold Separately. LiveScope sonar will not share with multiple displays wirelessly.

Network options in the 73sv include NMEA2000 and WiFi Connectivity. NMEA2000 allows you to connect and share numerical data across devices such as Autopilots, digital switching, AIS and more. Wi-Fi connectivity is built into every UHD2 73sv and allows your to wirelessly share sonar, waypoints and routes with another ECHOMAP UHD2 6", 7 or 9" Chartplotter while also enabling you the ability to pair with Garmin's Active Captain app on your compatible smartphone for access to the OneChart™ feature, software updates and more! Wirelessly connect to a Force Trolling Motor (sold separately) to create and follow routes, navigate to waypoints. control speed and even check battery! Panoptix LiveScope sonar will not share wirelessly to other displays.

Garmin ECHOMAP UHD2 73sv Ice Fishing Bundle with Garmin Navionics+ Lake Charts Box Contents

Each Garmin ECHOMAP UHD2 73sv Ice Fishing Bundle with Garmin Navionics+ Lake Charts Comes with:
  • ECHOMAP UHD2 73sv Chartplotter
  • GT10HN-IF Transducer (8-pin Transducer, with 8 pin-4 pin Adapter, 8ft Cable)
  • Tilt/Swivel Mount
  • Portable Bag
  • Base/Handle
  • Foam Float
  • Power Cable
  • Rechargeable Battery
  • Battery Charger
  • Documentation
  • 1-Year Warranty

Garmin ECHOMAP UHD2 73sv Ice Fishing Bundle with Garmin Navionics+ Lake Charts Key Features

  • Bright, Sunlight Readable 7-Inch Display with Key/Touch Interface
  • GT10HN-IF Transducer Operates on 130-300kHz with a Beamwidth of 16 or 7 Degrees
  • Built-in Flasher
  • Preloaded Garmin Navionics+ Charts for U.S. Lakes (Includes More than 23,000 Lakes)
  • Includes Convenient Portable Carrying Case
  • Size: 10.5" × 9.5" × 10.5"
