Veratron OceanLink 4.3” TFT Display Black

Free Ground Shipping!

Veratron OceanLink 4.3” TFT Display Black

The OceanLink Master 4.3-Inch Display is a multifunction display designed to help you monitor engine data and related sensor information. Monitor up to 4 engines with a single display! The integrated NMEA 2000 gateway easily receives data via analog or J1939 and distributes them via NMEA 2000. This versatile display is ideal for those seeking a single display for all of their vessel data!
  • SKUVR1352150001
  • MAN#A2C1352150001
  • ID#: 7981
(Rating 90)
Our Price:
562.49
MAP Price
Availability:
Usually Ships in 3-5 Days
Shipping:
Free Ground Shipping!
Condition:
Brand New

Versatile, 4.3-Inch Display with Sophisticated Design!

The Veratron OceanLink Master 4.3” TFT Display features a full color, optically bonded display for perfect readability even in direct sunlight. This device displays and distributes a variety of data received over a NMEA 2000 network, via SAE J1939, or through analogue sensors that are directly connected to the TFT display. Fully customizable, the OceanLink 4.3” master display can have up to 10 different data pages with single, dual, triple, or quad grid layouts allowing the most crucial of data to be seen when you need it most.

  • 1x NMEA 2000® connector
  • 1x SAE J1939 input
  • 4x Analog input
  • 1x Frequency input
  • 2x 4-20 mA output
  • 1x EasyLink data output
  • 1x Programmable alarm output 500 mA
  • Veratron OceanLink 4.3” TFT Display Black Box Contents

    Each Veratron OceanLink 4.3” TFT Display Black Comes with:
    • Veratron OceanLink 4.3” TFT Display Black
    • Wiring Harness
    • 2-Year Warranty

    Veratron OceanLink 4.3” TFT Display Black Black Key Features

    • Transmissive Layer Technology for Great Readability Even in Direct Sun.
    • Display Up To 10 Data Pages.
    • Optical Bonded Mineral Glass Lens.
    • IPX7 Protection Rating.
    • Connect Up To 4 Engines.
    • Size: 125 x 125 mm (Outer) 111 mm (Mounting Hole Diameter)
    Veratron OceanLink 4.3" Marine Display Manual Click Here
