View targets through premium glass showing distance, maps, navigation, and more

The Garmin Xero L60i Laser Rangefinder is a high end optical ranging device built for users who demand extreme precision, advanced mapping, and augmented reality performance in the field. Designed with a rugged and compact form factor, it measures 4.94 x 3.53 x 1.99 inches and carries an IPX7 water rating for reliable use in harsh environments. The unit weighs 0.80 pounds without batteries and 0.849 pounds with batteries installed, striking a balance between durability and portability. Its operating temperature range from negative 20 degrees Celsius to 60 degrees Celsius ensures dependable performance across a wide variety of conditions.

At the core of the Xero L60i is a DLP augmented reality display that overlays critical information directly onto the visual scene. The display resolution is 960 x 540 pixels and supports a multi color interface that enhances clarity and situational awareness. Optical performance includes 7x magnification, a 32 mm objective lens, and a 7 degree field of view, translating to 365 feet at 1,000 yards. Additional optical details such as an 18 mm eye relief, 4.6 mm exit pupil, and adjustable focus of plus or minus 4 diopters contribute to a comfortable and precise viewing experience.

Power is supplied by two AAA lithium batteries, which are included and provide up to 1,400 ranging actions based on a one second range and ten second display cycle. The device features a Class 1 laser with a precision rating of plus or minus 0.1 meters and accuracy of plus or minus 0.25 meters out to 1,000 meters and plus or minus 1.0 meter beyond that distance. In full sun conditions, the Xero L60i can range animals out to 1,375 meters, trees out to 1,800 meters, and retro reflective targets out to 5,000 meters. Under optimal conditions, those distances extend to 2,775 meters for animals, 3,600 meters for trees, and 7,000 meters for retro reflective targets.

The Xero L60i is packed with advanced navigation and ranging features. Built in sensors include a compass and barometer, while onboard mapping and 32 GB of internal memory allow users to store locations, tracks, and courses. Functions such as Laser Locate, Sensor Locate, visual recall, area calculation, and measuring distances between two points add versatility in the field. Angle compensated distance and archery ballistics are supported, and the device integrates an Applied Ballistics Ultralight solver through the AB Quantum app for enhanced ballistic calculations.

Connectivity further expands the capabilities of the Xero L60i. Bluetooth support allows pairing with the Garmin Explore app for mapping, data management, and Garmin Share functionality. A USB C interface is included for data transfer, and a carrying case comes standard for protection and transport. With its combination of long range performance, augmented reality display, onboard mapping, and advanced ballistic features, the Garmin Xero L60i stands as a premium solution for users who require professional grade ranging and situational awareness in demanding environments.
